Universal fan windshield washer nozzles: installation, adjustment, advantages

In many ways, the safety of traffic on the roadway depends on whether the road is clearly visible ahead. Various pollution in the form of stuck insects, splashes from rain or snow significantly worsen the survey of the route. In this case, can help universal fan nozzle windshield washer. Unlike conventional counterparts, they are more efficient.

universal fan windshield washer nozzles

The main advantages of the application

The presented devices allow spraying washing liquid over the entire surface of the glass. As for inkjet models, they make it possible to deliver the working environment directly to two sites, therefore, they are less effective.

Applying universal fan windshield washer nozzles, you can get the following benefits:

  • a significant reduction in the consumption of the used liquid due to the cleaning efficiency;
  • no traces of brushes, because the tool is evenly distributed throughout the plane;
  • increase the service life of the janitors, as they practically do not work dry.

The possibility of self-installation of elements allows you to avoid the costs required to pay for the work of specialists. The money will have to be spent only on the purchase of sprinklers, and they are relatively cheap.

replacement windshield washer nozzles

Certain disadvantages

In connection with the design features, the products are subject to frosting at low temperatures. This problem is particularly relevant in the northern regions, where there are severe frosts in winter. However, there is a way out of this situation. You can buy a heated windshield washer nozzle.

Another negative point is a significant reduction in visibility during the use of elements. Wash fluid gets into too large area of ​​glass. However, this effect is very short. Special inconvenience during operation usually does not occur.

Little about choosing

It is best to purchase universal fan nozzle windshield washer for a particular car.Most often they are supplied in an expanded configuration or as an additional option. If original models are not provided for any brand of vehicle, then third-party products can be used.

For example, models from Volvo S80 are suitable for many cars. They are quite actively installed on cars Mazda, Subaru and Toyota. A less expensive option is to buy Ssang Yong sprinklers. Products are also compatible with many models.

heated windshield washer nozzles

If the choice is made for the car Chevrolet Aveo, then it is better to purchase products of the brand Skoda. This manufacturer supplies universal windshield washer nozzles. Their price is only 300-400 rubles, but the quality characteristics are quite acceptable.

More about heating

Increasing the temperature of the working fluid is necessary in regions with relatively strong frosts. The presence of heating makes it possible to avoid the crystallization process inside the products. Warm liquid has a positive effect on the quality of cleaning. The material from which the brushes are made is heated, so that dirt is better removed from the surface.

Working windshield washer nozzles with heating is very simple.Inside the system is a portable heating element. Its shape may vary depending on the specific model. The liquid passes through a peculiar wire heater, after which it is sprayed.

There are other options for the implementation of heating. However, they are not able to prevent the formation of ice crystals directly in the holes of the spray device.

Self-replacement windshield washer nozzles

It is not difficult to remove inkjet analogs and install fan-type devices instead. Before the replacement of the windshield washer nozzles will begin, it is necessary to prepare additional elements:

  • the raising tee;
  • set of new hoses;
  • check valve.

Universal windshield washer nozzles price

The last component is required if it is not in the system. Its main purpose is to maintain a stable pressure in the inner part and to prevent premature draining of the liquid into the main tank. The valve is installed in front of the tee. When installed elsewhere, the head will be slightly reduced.

First of all, the hood is opened and the skin is removed, after which the tubes carrying the fluid supply are disconnected. Next dismantled nozzles installed previously.Standard clips are neatly released for this. Then the valve is connected if it was not in the system. Purchased items are inserted in regular places. New hoses are connected to them.

Tuning events

Directly at installation adjustment of windshield washer nozzles is made. Each driver chooses an option for themselves. You should not neglect adjusting measures, since the quality and the rate of decontamination will depend on this. Otherwise, there may be problems with the view during the ride when cleaning the front window.

If the jet nozzles have special nozzles that can be adjusted using a conventional needle, then the fan analogues after installation are unlikely to be adjusted. However, the liquid may not fall into the right place. Then a seal is placed under the front or back. If necessary, instead, you can use insulating tape, folded in several layers.

In some cases, you even have to remove one side of the plastic base of the product. This is done with the help of a file.However, most often enough measures for the installation of small linings.

Adjusting the windshield washer nozzles

Final part

Although universal fan windshield washer nozzles are quite effective, you shouldn't rush to replace inkjet counterparts, especially if they are functioning properly and were installed quite recently. These works can be carried out after a while, when the service life of the standard sprinklers has expired. Not always the replacement of such elements goes smoothly.
